Heat Pump Heating/Cooling Unit – Nevada JET HP

Categories Cooling and Heating - Stavoklima, Cooling and Heating Units

Heat Pump Heating/Cooling Unit – Nevada JET HP

The indoor unit of a high-efficiency, renewable energy heat pump system designed for tall industrial spaces. It connects to an outdoor unit using eco-friendly R410A refrigerant, providing powerful, cost-effective heating and cooling with excellent destratification for superior comfort and sustainability.

Product Description

Key Features & Benefits

Renewable Energy System
Part of an air-to-air heat pump system, using ambient air as a renewable energy source for highly efficient operation.
All-in-One Heating & Cooling
Provides powerful destratification heating in winter and effective cooling in summer from the same ceiling unit.
High Efficiency & Low Operating Cost
Heat pump technology delivers more energy (heat/cool) than the electrical energy it consumes, significantly reducing bills.
Eco-Friendly Refrigerant
Uses R410A, a modern refrigerant with zero ozone depletion potential (ODP), supporting environmental goals.
Built for Tall Spaces
Engineered to solve comfort challenges in high-ceiling industrial environments (3.8m to 13m), where standard systems fail.
Robust & Low Maintenance
Self-supporting zinc-coated structure (RAL 9010), IP54 rating, and maintenance-free EC fans ensure durability.

Technical Specifications

Air Volume Range

1,300 – 8,050 m³/h (adjustable in 4-10V steps).

System Type

Air-to-Air Heat Pump (Indoor Unit). Uses R410A refrigerant in a closed circuit.

Two Frame Sizes

N3 JET HP: For heights 3.8–9m. N4 JET HP: For heights 5–13m.

Heat Exchanger

3-row Cu/Al condenser /evaporator coil for efficient heat transfer with the refrigerant.

Fan Power

High-efficiency EC fan. Voltage: 230V (N3) or 400V (N4).

Outdoor Unit Range

Compatible with outdoor units from 33.5 kW up to 50 kW heating capacity.

System Overview

Component	Description	Key Benefit
Indoor Unit (Nevada JET HP)	Destratification fan coil with adjustable nozzles.	Even temperature distribution in tall spaces.
Outdoor Unit (Heat Pump)	Extracts renewable energy from ambient air. (33.5–50 kW).	High efficiency, low operating cost, uses R410A.
Control System	Unireg + Ditronic Touch or EX MODBUS module.	Full automation, scheduling, BMS integration.
Refrigerant Circuit	Closed-loop piping with R410A.	Freeze-proof, efficient heat transfer.

Installation & Control

Ceiling Suspension

Designed exclusively for under-ceiling mounting as the indoor unit of a split heat pump system.

Adjustable Nozzles

Nozzles adjustable from 25° to 55° for precise targeting of conditioned air across the floor area.

Smart Control System

Controlled via the Unireg HC/HP distribution board + Ditronic Touch EC controller for full local and BMS/MODBUS integration.

Seamless BMS Integration

Optional EX MODBUS control module allows direct, simplified integration into existing building management systems.

Freeze-Resistant Operation

Refrigerant circuit operates at very low temperatures (boiling point < -20°C), eliminating freeze risk unlike water systems.
